Chapter 1 3

Audio

q Codec : Realtek ALC833

q Compliant with Microsoft’s UAA (Universal Audio Architecture) support (rear only)

q 7.1+2 Channel Audio Support (ALC833 codec series provide 10 DAC channels that

simultaneously suppport 7.1 soud playback, plus 2 channels of independent stereo sound output

through the front panel stereo output).

q 16/20/24 bit S/PDIF-OUT supports 44.1K/48K/96K/192KHz sample rate; 16/20/24bit S/PDIF-IN

supports 44.1K/48K/96KHz sample rate

q Reserved disable function on BIOS side. Default is enabled.

LAN

q Controller : PCI-E Giga LAN chip with manageability function

q LAN Chip : Marvell 88E116

q Should be worked under 10/100/1000 Mbs environment

q Integrated 1.25 GHz SERDES for 1000BASE-X fiber applic

q Reserved disabled function on both hardware & BIOS side. Default is enabled

SERDES : serializer/deserializer: a device that takes parallel data, such as an 8-bit signal, and converts it into

a serial stream for transmission on a serial link. At the other end, it converts the serial data back to parallel.

USB

q Controller : nVidia MCP51

q Connectors Quantity : 8

q 4 rear connectorsFour for front daughter board (Pin:2*5 )

q USB 2.0/1.1

System LED Definition

On-Board Connector

q Rear I/O Connectors

q 1 D-sub (CRT) Port

q 1 DVI Port

q 1 GigaLAN Port

q 4 USB Ports

q 3 Ports Jack

q 1 19V DC-in Jack

q 1 IEEE 1394 port

q On-Board Connectos

q 1 CPU Socket

Chasis Bezel Power LED HDD LED LAN LED ODD LED

S0 S1,S3 S4,S5

H701 V751 Blue Blue Blinking OFF Blue Blue Blue

H500 H500 Green Green Blinking OFF Green Green N/A

H401

V451 Blue Blue Blinking OFF Blue Blue Blue

A451 Blue Blue Blinking OFF Blue Blue Blue
