Chapter 1 7

Your Acer Notebook tour

After knowing your computer features, let us show you around your new AcerPower computer.

Front and rear panel

Your computer's front and rear panels consist of the following:

Icon Component Icon Component

Eject button DVI port

Power button CRT/LCD monitor port

Hard disk drive indicator OBR (One Button Recovery) button

LAN indicator/ Network port Line-out jack

USB ports Microphone-in jack

Kensington lock Headphone/Speaker-out/line-out port

DC-in jack Line-in jack

IEEE 1394 port Media card reader

FM FM radio input jack TV-OUT S-video output jack (for selected

models)

TV V antenna/cable input jack SPDIF Coaxial digital audio output jack

A/V input connector
