12 Chapter 1

LAN Interface

Item Specification

LAN Controller PHY-88E116 LAN Controllers

LAN Controller Resident Bus PCI Bus

LAN Port ONE RJ-45 on board

Function Control Enable/Disable by BIOS Setup

IDE Interface

Item Specification

IDE Controller Built-in nVidia MCP51

IDE Controller Resident Bus PCI bus

Number 40 pin PATA slot 1

q Device Type Support HDD, CD-ROM, CD-RW, DVD-ROM,Combo,DVD burner

q Transfer Rate Support PIO 0/1/2/3/4

q ATA Mode 33/66/100

Number STAT IDE slot 4

q Device Type Support HDD,CD-ROM,CD-RW,DVD-ROM,DVD-RW,DVD+RW,DVD Dual,DVD

Supermultiplus

Supports LS-120 Yes

Supports bootable CD-ROM Yes

Function Control Enable/Disable by BIOS setup

Serial Port (No serial port for this model)

Item Specification

Serial port controller LPC47M182

Serial port controller resident bus LPC Bus

Number of serial port 1

Serial port location Rear panel

16550 UART support Yes

Connector type 9-pin D-type female connector

USB Port

Item Specification

Universal HCI USB 2.0/1.1

Controller Built-in nVidia MCP51

Number of the connectors 8

Location Rear : 4

Front : 4

USB Class Support legacy keyboard for legacy mode
